Purpose:
It is suitable for screening powder and granular materials in metallurgical, mining, chemical, building materials and casting works they. Mr. the same time of screening,add ventilation and dust removal to cool down.
Characteristic:
Feed at large end of hexagon, screen area is equivalent to increase 30-40%near theoretical speed, and materials from screen banner. Stable operation,reliable operation and fine screening. high pointWash down to achieve crushing and fine screening;
Cold drawn stainless steel high-strength coarse wire woven net, long service, life, It can electively screen and remove more than 4-on. used sand Mm hard particles make the quality of molding sand uniform and improve the yield of castings.
The pulling and pressing mode of the screen is fixed, the screen surbrace is light and not easy to be broken, and the rebound crushing after
Strong ventilation, mud content control, and achieve a certain cooling effect, At the same time, it can reduce the condentation and slightly. is good,And easy to replace, of the wet,hot and sticky materials on the sieve hole.
Main technical parameters
Parameters Model | Productivity(t/h) | Driving power(kw) | screen cylindox Right angle(men | (mm) Mesh size(mm) | Recornmended air volume (-/) |
S4310 | 20-40 | 4 | 1100 | 6×16 | 6000 |
S4313 | 40-60 | 5.5 | 1300 | 6×16 | 7000 |
S4315 | 70-90 | 7.5 | 1500 | 6×16 | 8000 |
S4318 | 90-110 | 11 | 1800 | 6×16 | 10000 |
S4321 | 110-130 | 18.5 | 2100 | 6×16 | 13000 |
